12 Layers 3 order HDl Communication PCB

PCB is known as the “mother of electronic system products”. As the basic material of electronic products, PCB has a broad demand market.
The downstream application fields include communication computers, consumer electronics, industrial control and medical, automotive electronics, aerospace, etc.
Among them, communication and computer are the largest application sectors of PCB, accounting for more than 25%.

In the field of communication, PCB is widely used in wireless network transmission network, data communication, fixed network broadband, etc.
Related PCB products include backplane PCB, high-speed PCB, multi-layer PCB, high-frequency PCB, microwave PCB, multi-functional metal-based PCB board, etc.

In wireless base stations, bearer networks, transmission networks, and core network hardware facilities, the application of PCB hardware will increase significantly.
At the same time, 5G terminal equipment such as mobile phones and smart watches also need to update communication technology, which will also increase the demand for communication PCB boards.

ZBpcb has a full set of communication circuit board production equipment to reduce the risk of outsourcing production.
ZBpcb is specially equipped with plasma degumming machines and ultra-long board parallel exposure machines for the communication industry.
The exposure length can reach 2m. ZBpcb specially introduces surface treatment production lines rarely seen in the communication industry, such as silver plating, tin plating, silver immersion, and tin immersion.

ZBpcb has superb process capabilities to meet the needs of communication PCBs.

ZBpcb has mature mixing technology: FR4+PTFE, FR4+408hr, FR4+Rogers, ceramic+FR4.

ZBpcb can produce 1.5mil/1.5mil line width, and the impedance tolerance can be controlled within ±5%.
